氣動壓力機(jī)JH21-125T
TECHNICAL PARAMETERS:
Description | Unit | Specification |
Mechanical Pressure | Ton | 125 |
Nominal Force | KN | 1250 |
Nominal stroke | mm | 6 |
Slide stroke (car ride) | mm | 160 |
(SPM) Strokes Per Minute | Min | 50 |
Maximum Die Height | mm | 350 |
Die Height Adjustment | mm | 80 |
Table area (FB*LR) | mm | 680*1150 |
Thickness of the reinforcement (top of the table) | mm | 140 |
Opening the bed (Dia*F-B*L-R) | mm | 420*540 |
Aerial table (FB*LR) | mm | 540*680 |
Stem hole (Diameter Depth) | mm | Φ 60*80 |
Between columns | mm | 760 |
Engine power | Kw | 11= 14.75 (Available to 15 hp) |
Electrical Power Supply | Vca | 440 (It depends on the customer's need) |
Dimensions | mm | 1850*1650*3060 |
Weight | Kg | 10,000 |
Between the centerof the slide and the frame | mm | 350 |
Transmission Control and Brake Systems:
1. Carbon steel plate reservoir and frame for lubricant.
2. The main engine adopts a Siemens motor.
3. Dry pneumatic friction clutch and brake.
4. Combined lubrication system.
5. Six-sided rectangular elongation guide; JH21-315B/400B adopts eight-sided extension guide rail.
6. Hydraulic overload protection device.
7. Manual adjustment, of which scale indication, digital display adopts eight-sided extension guide; Hydraulic load protection device. Electrically adjustable, digital display with electrically adjustable with PLC.
8. Lifting Balance Cylinder Device (except JH21-16).
9. Imported duplex solenoid valve.
10. Automatic centralized lubrication system.
11. The balancing cylinder adopts manual oil lubrication system.
12. Equipped with a set of blowing device.
13. Integrated panel (with electronic cam).
14. International brand PLC control.
15. Buttons, switches, air switches from international brands;
16. Optional: wet clutch, air cushion (airbag type or cylinder type), automatic feeding shaft device, photoelectric protection device, slider on the feeding device, with a variety of automation equipment.
17. New machine with a year of manufacture after 2022.
18. It does not present surface defects such as bumps, cracks, deformations, etc.
19. It includes tools and accessories necessary for its correct installation and operation.
20. Maintenance training.
21. Installation, commissioning and operation.
22. Training in operation and functioning.
23. Warranty: 12 months.
24. Voltage: as per customer's request (440 Vac).
25. Color: according to customer's request.
26. Automatic centralized lubrication system
Additional Documentation
1. Letter of Warranty against manufacturing defects is included.
2. Additional Manuals.
a. Maintenance Manual.
b. Programming Manual.
c. Operation Manual.
